Characteristic features:
1. OMR OMRX series motor adapt the advanced Geroler gear set design with shaft distribution flow, which can automatically compensate in operating with high pressure, provide reliable and smooth operation, high efficiency and long life.
2. Advanced manufacturing devices for the Gerolor gear set, which use low pressure of start-up, provide smooth, reliable operation and high efficiency.
3. Shaft seal can bear high pressure of back and the motor can be used in parallel or series.
4. Special design in the driver-linker and prolong operating life.
5. Special design for distribution system can meet the requirement of low noise of unit.
6. Compact volume and easy installation.
Applications: Hydraulic system, engineering machine, industry machine
Specifications:
| Displacement (ml/r) | 50 | 63 | 80 | 100 | 125 | 160 | 200 | 250 | 315 | 400 | 500 |
| flow (LPM) | cont. | 40 | 40 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 |
| int. | 50 | 50 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 |
| speed (RPM) | cont. | 755 | 630 | 750 | 600 | 475 | 375 | 300 | 240 | 190 | 160 | 110 |
| int. | 970 | 790 | 940 | 750 | 600 | 470 | 375 | 300 | 240 | 200 | 128 |
| pressure (MPa) | cont. | 14 | 14 | 17.5 | 17.5 | 17.5 | 16.5 | 13 | 11 | 8.5 | 8.5 | 8 |
| int. | 17.5 | 17.5 | 20 | 20 | 20 | 20 | 17.5 | 14 | 11.5 | 11.5 | 9 |
| torque (N*m) | cont. | 100 | 124 | 190 | 240 | 292 | 363 | 358 | 352 | 360 | 420 | 464 |
| int. | 126 | 156 | 220 | 280 | 340 | 430 | 448 | 470 | 470 | 548 | 580 |
| output power (KW) | cont. | 9.5 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 | 10 | 7 | 6 | 5 | 5 |
| int. | 11.2 | 15 | 15 | 15 | 14.5 | 14 | 13 | 9.5 | 9 | 8 | 8 |
Features:
Compact in design with disc valving and Geroler.
High pressure capacity shaft seal.
Design and manufacture of the spline and drives give the motor durability.
Wide variery of mounting flanges,shafts,ports and speed provides design flexibility.
Direction of shaft rotation and speed can be controlled easily and smoothly.
Best combination of high efficiency and economy in medium duty applications.
Packing&Delivery&After-sale:
1. Standard wooden case or cartonbox
2. Safety for long-distance transportation
3. All of the productions will be checked carefully before delivery
Our Advantage:
1. Quick response within 12 hours
2. Accept small order(MOQ:1pcs)
3. Custom service.Unusual packaging,standard packing or as customer required
4. Excellent after-sales service
5. Strict quality control system.100% factory testing and inspection personnel in accordance with international standards for the high-frequency sampling, to ensure the quality of products manufactured
6. Accept ODM&OEM
Descrition:
Compact in design with spool valving and Geroler
Imported high pressure capacity shaft seal
Wide variety of mounting flanges, shafts, ports
and speed provides design flexibility
Direction of shaft rotation and speed can be controlled easily and smoothly
Best combination of efficiency and economy in medium duty applications
Competitive Advantage: Good quality, Complete Series, Competitive price and Best service.
Packing:
Transportation:
1. who are we?
We are based in Jining, China, start from 2003
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3. what can you buy from us?
Hydraulic motor
4. How long is the Warranty?
One-year warranty.
5. What is your payment terms?
Re: 100% in advance, long-term dealer 30% in advance, 70% beofre shipping.
6. How about the delivery time?
Normal Models within 2 days, unusual models and bulk order within 5-10 days.
